Transceiver CB mobile met 10 & 12 mtr band . Met data aansluiting


FEATURES, FUNCTIONS AND SPECIFICATIONS:
- Rotary switch and Up/down channel selector
- VFO Mode
- Volume adjustment and ON/OFF
- RF Power
- Manual squelch and ASC
- Multi-function LCD display
- Frequencies display
- S-meter
- Public Address
- Vox function (Hands free)
- ANL filter , NB and HI-CUT
- RF Gain / Mike gain
- Clarifier
- Channels and memories scan
- 6 Memories
- CTCSS (38 tones)
- DCS (104 codes)
- Dim
- MENU fonction key
- Beep Function
- Roger Beep
- Mode switch AM/FM/LSB/USB/CW
- Dual watch
- Key locking
- SWR (Power Reading /SWR)
- Preset 9/19
- TOT (Time Out Timer) adjustable
- Front microphone plug
- External loudspeaker jack
NOTE: This transceiver has RX-Audio without the microphone plugged in.
PACKING INCLUDES:
1 Pc of Transceiver
1 Pc of Power Cord with Fuse
1 Pc of Microphone and its hanger
1 Pc of Mounting Bracket with Fixing Screws
1 Pc of User Manual
MICROPHONE:
6-Pin Microphone, Up/Down function, President Wiring.
MICROPHONE WIRING:
Pin 1 Modulation
Pin 2 RX
Pin 3 TX - UP/DOWN
Pin 4
Pin 5 Ground
Pin 6 Power Supply

FEATURES, FUNCTIONS AND SPECIFICATIONS:

- Rotary switch and Up/down channel selector

- VFO Mode

- Volume adjustment and ON/OFF

- RF Power

- Manual squelch and ASC

- Multi-function LCD display

- Frequencies display

- S-meter

- Public Address

- Vox function (Hands free)

- ANL filter , NB and HI-CUT

- RF Gain / Mike gain

- Clarifier

- Channels and memories scan

- 6 Memories

- CTCSS (38 tones)

- DCS (104 codes)

- Dim

- MENU fonction key

- Beep Function

- Roger Beep

- Mode switch AM/FM/LSB/USB/CW

- Dual watch

- Key locking

- SWR (Power Reading /SWR)

- Preset 9/19

- TOT (Time Out Timer) adjustable

- Front microphone plug

- External loudspeaker jack


NOTE: This transceiver has RX-Audio without the microphone plugged in.


PACKING INCLUDES:

1 Pc of Transceiver

1 Pc of Power Cord with Fuse

1 Pc of Microphone and its hanger

1 Pc of Mounting Bracket with Fixing Screws

1 Pc of User Manual


MICROPHONE:

6-Pin Microphone, Up/Down function, President Wiring.


MICROPHONE WIRING:

Pin 1 Modulation

Pin 2 RX

Pin 3 TX - UP/DOWN

Pin 4

Pin 5 Ground

Pin 6 Power Supply


Geef beoordeling

Note: HTML-code wordt niet vertaald!
    Slecht           Goed

President Lincoln-2 V3 Plus

  • Merk: President
  • Model: Lincoln-2 V3 Plus
  • Beschikbaarheid: 2-3 Days
  • € 325,00

  • Excl. BTW: € 268,60
